CIP/SIP as One of the Main Challenges of the Process Industry

Freudenberg Sealing Technologies offers highly resistant materials that reliably withstand demanding CIP/SIP media and processes.

CIP/SIP (Cleaning In Place/ Sterilization In Place) is a common process in the food and beverage industry. Its key advantage is that it constitutes a fully automatic cleaning process that eliminates the need for disassembling equipment and machine parts – and for a final visual inspection. But CIP/SIP requires special components that can withstand cleaning media and high temperatures.

Freudenberg Sealing Technologies offers seals made of special materials suited to these conditions. They are highly resistant to aggressive cleaning agents based on acids, lye, and peroxide as well as high temperatures (steam as high as +284 °F). Our product portfolio also includes screw systems and other components that are free of dead space.

Freudenberg has carried out extensive exposure testing using the highest recommended operational concentrations and temperatures. Consisting of over 200 compositions and 5,100 measurements, our database for CIP/SIP cleaning agents forms a solid basis for the CIP/SIP Guide. It enables you to find the right material for the cleaning agents explained below.

CLASS DETAIL PRODUCT OPERATING
CONCENTRATION (%)
TEMPERATURE EXPOSURE TIME (MIN.)
CIP or circulation cleaners containing nitric acid and surfactants Acidplus VA 35 0.5 – 2.0 +20 to +80 °C
(+68 to +176 °F)
Not specified
CIP or circulation cleaners containing formic acid and surfactants Beta VA 11 0.5 – 3.0 +10 to +70 °C
(+50 to +158 °F)
30 – 60
CIP or circulation cleaners containing phosphoric acid and surfactants Divbrau VA 10 1.0 – 4.0 +10 to +70 °C
(+50 to +158 °F)
20 – 60
Phosphoric acid-based foam cleaners Acifoam VF 10 3.0 – 10.0 +20 to +40 °C
(+68 to +104 °F)
Not specified
Alkaline, single-phase cleaners containing EDTA for circulation cleaning Solo VC 27 0.5 – 5.0 +40 to +80 °C
(+104 to +176 °F)
Not specified
CIP or circulation cleaners containing bases and surfactants Highstar VC 77 0.5 – 5.0 +40 to +80 °C
(+104 to +176 °F)
Not specified
Alkali gel cleaners Powergel VG 1 2.0 – 10.0 +20 to +40 °C
(+68 to +104 °F)
Not specified
Chlorinated alkali CIP or circulation cleaners Divo CIP VC 94 0.3 – 3.0 +20 to +60 °C
(+68 to +140 °F)
Not specified
Hypochlorite-based disinfectants Divosan Hypochlorite
VT 3
0.25 – 1.0 Room temperature Not specified
Cleaning boosters containing surfactants, oxidants Divo Peroxy 0.2 – 0.5 +20 to +80 °C
(+68 to +176 °F)
Not specified
Disinfectants containing peracetic acid Divosan forte VT 6 0.04 – 2.0 +20 to +60 °C
(+68 to +140 °F)
Not specified
Amphoteric surfactant-based disinfectants TEGO 2000 VT 25 0.25 – 1.0 Room temperature > 20
CIP/SIP

CIP/SIP GUIDE

Just a few clicks and you receive a first assessment of suitable materials or cleaning agents.

Try it out now!
